Automatic V-Shapes packaging machine Model Alpha

With a wide range of filling volumes and different customizable layouts available, the Alpha machine for packaging single-portion packets is distinctive for its reduced size and compact modular system.

The modern design of this packaging machine hides an advanced technological heart of the latest generation.

The technology of its brushless motors and the accurate systems of dosing prevent anti-economical overfills on volumes from 0.2 ml to 40 ml.

Bag types

Products types

Technical Info
Production capacity up to 300 units/minute
Time for packet size change 30 minutes
Number of packaging lines 6
Dimensions and maximum weight of film reels Left shaft 600mm , Right shaft 400mm
Film reel consumption Up to 5000mm /min
Standard weld dimensions 5 mm
Dimensions of V-Shapes packets Height from 50 to 100mm , Width from 40 to 100mm
Air Pressure 7 bar, 600 Nl/H
Electric power 28 Kwh
Weight (maximum) 3000 kg
Machine Footprint 2500mm x 2000mm x 2000mm (H)
